Basic Configurations
Working modeAC mode Routing mode
Internet access modePPPoE DHCP Static IP
Self Organizing NetowkYes
Maximum number of devices that can be managed128
Maximum number of APs (routing mode)1000
Maximum number of APs (AC mode)1000
Ethernet Switching
VLANYes
Maximum number of VLANs supported by all LAN interfaces128
LLDPNo
RLDPNo
STPNo
IP Routing
Load balancingYes
Static routingIPv4 and IPv6 Static route
Maximum number of IPv4 static routes500
Maximum number of IPv6 static routes500
PBRIPv4 and IPv6 PBR
Number of IPv4 PBR entries30
Number of IPv6 PBR entries30
URL-based routingYes
RIPYes
Number of RIP routes1000
BGPYes
Number of BGP routes10000
OSPFYes
Number of OSPFv2 instances16
Number of OSPF neighbors on a point-to-point interface64
Number of OSPFv3 routes10000
Number of dynamic IPv4 routes1000
Number of dynamic IPv6 routes1000
IS-ISNo
Security
ACLYes
DHCP snoopingNo
IP-MAC bindingYes
MAC address filteringYes
Security zoneYes
Local attack defenseYes
Limiting the number of connectionsYes
Multicast rate limitNo
Network sharing preventionYes
Authentication
Local portal authenticationSMS-based authentication One-click authentication Authorization-based authentication QR code authentication Authentication (IP address-based) across Layer 3 switches Self-service logout
Cloud portal authenticationCustom portal page Delivery through cloud portal page One-click login to cloud portal page Account-based authentication Voucher authentication SMS-based authentication supported by cloud portal page
Third-party authenticationWISPr for third-party portal authentication Wi-FiDog for third-party portal authentication
MAB on CloudYes
MAB for local authenticationYes
MAB for RADIUS-based authenticationYes
802.1X authenticationYes
PPPoE authenticationYes
VPN & VPN Performance
Site-to-Site VPNIPsec VPN WireGuard
Client-to-Site VPNL2TP VPN L2TP over IPSec VPN OpenVPN PPTP VPN WireGuard
L2TP VPN bandwidth1150 Mbps
PPTP VPN bandwidth1450 Mbps
OpenVPN bandwidth300 Mbps
IPsec VPN bandwidth730 Mbps
IPv6 IPsec VPN bandwidth900 Mbps
WireGuard performance1200 Mbps
L2TP over IPsec bandwidth750 Mbps
SD-WANYes
SD-WAN performance1200 Mbps
Gateway Features
User Behavior Management (UBM)Yes
Application controlYes
Flow controlYes
Traffic auditYes
Audit logYes
Local storage of traffic audit logsYes
IP Service
ARPYes
Proxy ARPNo
Maximum number of ARP entries4096
DDNSYes
DHCPYes
DNSYes
IPTVYes
IPv4/IPv6Yes
NATYes
Number of port mapping entries512
UPnPYes
MulticastNo
WLAN
AP managementWi-Fi RF parameters Managing clients Configuring an allowlist and a blocklist 802.1X authentication AP Mesh WQoS 802.11k/v roaming AP portal authentication AP load balancing AP LEDs Layer 2 isolation Configuring the power supply mode of the AP on Cloud
Maximum number of SSIDs8
Client associationYes
Network Management and Monitoring
Web managementYes
Cloud managementUpgrading device software version through App Restarting devices through App Remotely monitoring devices through App Self organizing network through code scanning Cloud-based O&M Cloud-based upgrade
Management on AppYes
Web login informationYes
HTTP loginYes
HTTPS loginYes
NTPNTP client
Fault diagnosisYes
TelnetNo
SSHNo
File transferNo
SyslogYes
SNMPYes
RLOGYes
Fan speed adjustmentNo
Fault self-diagnosisYes
StackingNo
VRRPNo
