System Specifications
Switching capacity16 Gbps(bit/s)
Forwarding rate11.90 Mpps
Buffer size8.4 Mbit
CPUsingle-core processor, 500 MHz clock frequency
Flash memory8 MB
System Performance Capacity
Recommended camera limit200W H265: 100
400W H265: 50
Power supply and Consumption
Power methodDC adapter:
● Rated input voltage: 100 V AC to 240 V AC, 50 Hz to 60 Hz
● Maximum input voltage: 90 V AC to 264 V AC, 47 Hz to 63 Hz
● Rated input current: 0.2 A
Output:
● Rated output voltage: 5 V DC
● Maximum output current: 1 A
Max. Power Consumption3.5 W
Heat Dissipation11.942 BTU/hr
Environment and Reliability
Surge protectionService port: ±6 kV for common mode
Power connector: ±4 kV for common mode and ±2 kV for differential mode
Operating temperature0°C～45°C（32°F～113°F）
Storage temperature–40°C to +70°C (–40°F to +158°F)
Operating humidity10% RH to 90% RH (non-condensing)
Storage humidity5% RH to 95% RH (non-condensing)
FanFanless design
CoolingNatural cooling
Altitude–500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.)
MTBF200,000 hours
ESD protectionAir discharge: 8 kV
Contact discharge: 6 kV
